233kwh Home Br Solar Carton and Pallet Energy Storage Solution

1 / 5

233kwh Home Br Solar Carton and Pallet Energy Storage Solution

Customization:	Available
After-sales Service:	After- Sales Service
Warranty:	3 Years, 5 Years

Send Inquiry

Product Description

Basic Specifications

Condition

New

Certification

ISO, CE

Application

Home, Industrial, Commercial, School, Factory

Specification

100kwh, 233kwh

Type of Cell

Lithium Iron Phosphate(LFP)

Cooling

Liquid Cooling

Protection Class

IP55

Rated Capacity

5.01 Mwh

Origin

China

Technical Parameters

Items	Parameters
Type of cell	Lithium Iron Phosphate(LFP)
Cell parameter	3.2V/314Ah
Max. charge/discharge power	0.5C
Configuration of system	1P416S×12
Rated capacity	5.01 MWh
Rated voltage	1331.2V
Voltage range	1164.8~1497.6V
Cooling method	Liquid Cooling
Operating temperature	−30~50ºC
Humidity	≤95%RH, no condensation
IP grade	IP55
Fire protection	Temperature sensor + Smoke detector + Combustible gas detector + Deflagration venting + Fire extinguishing gas + Water sprinkler
Dimension(L×W×H)	6058×2438×2896mm

Packaging & Delivery

Package Size

110.00cm * 140.00cm * 238.00cm

Gross Weight

2000.000kg

Package Type

Carton and Pallet

Frequently Asked Questions

What type of battery cells are used in this system?

The system utilizes high-quality Lithium Iron Phosphate (LFP) cells, known for their safety and long cycle life.

How is the system cooled?

This energy storage solution uses an advanced Liquid Cooling method to maintain optimal operating temperatures.

What is the protection rating for outdoor use?

The system is rated IP55, providing significant protection against dust and water ingress, suitable for various environments.

What safety features are included for fire protection?

It includes a comprehensive safety suite: temperature sensors, smoke detectors, combustible gas detectors, deflagration venting, and fire extinguishing systems.

Can this system be used at high altitudes?

Yes, the system is designed to operate efficiently at altitudes up to 3000 meters.
