5kw 15kw 20kw Hybrid off-Grid Solar Photovoltaic Panel Battery Backup Home Energy Storage Residential Solar System

Customization: Available
After-sales Service: Yes
Warranty: 18 Months

Product Description

📊 Basic Information
Model NO.
WHC-HVM-5.5KW-800
Certification
CE, RoHS
Application
Home Residential
Load Power
5500W
System Type
Hybrid Solar System
Output Voltage
AC220V
Battery Type
Gel / Lead Acid
Solar Panel
Mono Solar Panel
💡 Product Description
Solar System Overview Solar Setup

The Solar Energy System, also known as an off-grid solar system, is the most cost-effective type for solar setups. It is a complete configuration that comes with highly efficient solar panels, an off-grid solar inverter, lithium-ion or gel batteries, and other standard solar accessories. This system provides continuous electricity and significantly reduces electricity bills.

📋 Technical Parameters
WHC-HVM-5.5KW-800 Specifications
ItemModelSpecificationsQty
Solar InverterHVM5.5KW48V 5.5KW & MPPT 500V 100A1 pc
Solar PanelWHC-450M-120Mono 34V 450W8 pcs
Solar BatteryWHC200-12Gel Battery 12V 200AH4 pcs
PV Cable6 MM²100m Length2 units
MC4ConnectorWaterproof MC42 units
🔍 Detailed Components
Hybrid Inverter

Solar Hybrid Inverter

  • 48V 5.5KW High Efficiency
  • PV Input: 500V 100A
  • Output: 220V 50Hz
  • Pure Sine Wave for long lifecycle

Mono Solar Panel

  • Max Power Voltage: 34.2V
  • Max Power Current: 13.15A
  • Dimensions: 1909*1134*35mm
  • Weight: 24.5KG
Mono Panel
Gel Battery

Solar Gel Battery

  • 12V 200AH Maintenance Free
  • Internal Resistance: Approx. 3mΩ
  • Float Charging: 13.5V to 13.8V
  • Dimensions: 522*238*222mm
📜 Certifications & Global Projects
Certificates Solar Projects
🏭 Production & Manufacturing
Factory

Founded in 2009, our manufacturing facility specializes in the solar field with over 15 years of experience. Our product range includes solar batteries, inverters, panels, and street lights. We hold 11 invention patents and have registered trademarks in 37 countries, providing original market protection and high-quality energy solutions worldwide.

Production Line 1 Production Line 2 Production Line 3
Frequently Asked Questions
Q1: Can this 5.5KW system run my whole house?
A: Yes, it is designed for residential use and can support common household loads up to 5500W, including lights, fans, and appliances.
Q2: What is the lifespan of the Gel Battery?
A: The high-quality gel batteries are designed for long-cycle life, typically providing several years of reliable service depending on discharge depth.
Q3: Are the solar panels weather resistant?
A: Absolutely. The Mono solar panels come with an aluminum alloy frame and are built to withstand outdoor conditions on flat roofs or ground sites.
Q4: Does the inverter support both solar and utility charging?
A: Yes, it is a hybrid system that can manage power from solar panels and the grid to ensure 24-hour electricity.
Q5: Is the installation complicated?
A: The system includes standard MC4 connectors and PV cables. While professional installation is recommended, it is designed for efficient setup.
